The silicon diode shown in figure is rated for a maximum current of 10 mA. Calculate the minimum value of resistor R. Assume the forward voltage drop across the diode to be 0.7 V.

The silicon diode shown in figure is rated for a maximum current of 10 mA. Calculate the minimum value of resistor R. Assume the forward voltage drop across the diode to be 0.7 V.
